| DIMENSIONS |
H = 137, W = 64, D = 31mm |
| ANTENNA IMPEDANCE |
50 ohm |
| CCIR, ZVEI, EEA & EIA |
En- & decoder up to 3 sequencies of each 8 tones, programable tone lenght, lenght of first tone & pre-ample. Individual call. |
| CHANNEL SPACING |
12,5 / 20 / 25 KHz |
| CTCSS / DCS |
En-/ Decoder. The channels can be programmed individually with different CTCSS tones. |
| DIMENSIONS INCL. BATTERY |
H = 137, W = 64, D = 31mm |
| FREQUENCY ERROR |
± 2 ppm |
| MAX. DEVIATION |
± 5 KHz / 25 KHz channel |
| MODE OF OPERATION |
Simplex/Semi-Duplex |
| MODULATION DISTORTION |
< 5 % @ ± 3,0 KHz |
| OUTPUT POWER |
Programmable 0.5 - 2 Watt |
| RF-BANDWIDTH |
64 MHz |
| SENSITIVITY |
0,45 μV |
| SIGNAL / NOISE RATIO |
40 dB |
| SQUELCH LEVEL |
Programmable |
| STAND-BY |
5 % TX, 5 % RX & 90 % Standby 3000 mAh battery : 16 hours |
| TEMPERATURE RANGE |
-20 °C to +55 °C |
| WEIGHT INCL. BATTERY |
250 g. |
